轨道车辆制造 / “一带一路”轨道交通系列规划教材
定价：￥118.00
作者： 邹骅
出版时间：2022-02
出版社：中国铁道出版社
- 中国铁道出版社
- 9787113287061
- 1-1
- 440042
- 60269928-2
- 16开
- 2022-02
- 331
- 工学
- 交通运输类
- 装备制造大类
- 铁道运输类
- 铁道车辆
- 本科
作者简介
内容简介
ThebookisoneofTheBeltandRoad″railtransitseriesplanningtextbooks.Itmainlyintroduces
themanufacturingprocessofrailwayEMUbogieandcarbody.Itisdividedinto5chapters.Chapter1
introducesthemachiningofEMUbogie;Chapter2introducestheassemblyofEMUbogie;Chapter3
introducesthepunchingofcarbodypartsofEMU;Chapter4introducestheweldingprocessforcar
bodyassemblyofEMU;Chapter5introducesthemanufacturingofEMU.
Thebookcanbeusedasateachingmaterialforrailvehiclerelatedmajorsofuniversityorcollege.
Itisalsoavailableforengineeringtechniciansmajoringinvehicleengineeringandurbanrailtransit
vehicle.
themanufacturingprocessofrailwayEMUbogieandcarbody.Itisdividedinto5chapters.Chapter1
introducesthemachiningofEMUbogie;Chapter2introducestheassemblyofEMUbogie;Chapter3
introducesthepunchingofcarbodypartsofEMU;Chapter4introducestheweldingprocessforcar
bodyassemblyofEMU;Chapter5introducesthemanufacturingofEMU.
Thebookcanbeusedasateachingmaterialforrailvehiclerelatedmajorsofuniversityorcollege.
Itisalsoavailableforengineeringtechniciansmajoringinvehicleengineeringandurbanrailtransit
vehicle.
目录
Chapter1MachiningofEMUBogie……………………………………………………001
1.1EstablishmentofMachiningProcessSpecification…………………………………001
1.2ClampDesignBasis…………………………………………………………………030
1.3MachiningofTypicalBogieParts……………………………………………………055
1.4MachiningEquipmentforTypicalBogieParts………………………………………078
ReviewQuestions…………………………………………………………………………081
Chapter2AssemblyofEMUBogie………………………………………………………082
2.1ElementaryKnowledgeofMechanicalAssembly……………………………………082
2.2WheelsetAssembly…………………………………………………………………090
2.3AxleBoxAssembly…………………………………………………………………103
2.4AssemblyofTypicalBogie…………………………………………………………119
ReviewQuestions…………………………………………………………………………128
Chapter3PunchingofCarBodyPartsofEMU………………………………………129
3.1Overview……………………………………………………………………………129
3.2Stamping……………………………………………………………………………133
3.3Bending………………………………………………………………………………159
3.4Drawing………………………………………………………………………………168
3.5ColdExtrusion………………………………………………………………………177
3.6EstablishmentofPunchingProcessSpecification……………………………………182
ReviewQuestions…………………………………………………………………………191
Chapter4WeldingProcessforCarBodyAssemblyofEMU…………………………192
4.1WeldingMethodsandEquipment……………………………………………………192
4.2StrengthCalculationofWeldedStructureandJoint…………………………………215
4.3Weldingdeformationofcarbodystructure…………………………………………227
4.4WeldingofStainlessSteelCarBody…………………………………………………240
4.5WeldingofAluminumAlloyCarBody………………………………………………244
ReviewQuestions…………………………………………………………………………267
Chapter5ManufacturingofEMU………………………………………………………268
5.1CompositionofCarBodyStructuresandMainParameters…………………………268
5.2UnderframeAssemblyandWeldingProcess…………………………………………289
5.3AssemblyandWeldingProcessofSideWall………………………………………294
5.4RoofAssemblyandWeldingProcess………………………………………………301
5.5AssemblyandWeldingProcessofEndWall………………………………………302
5.6AssemblyandWeldingProcessofDriver′sCab……………………………………303
5.7GeneralAssemblyofCarBody………………………………………………………306
5.8GeneralAssemblyofEMU…………………………………………………………309
ReviewQuestions…………………………………………………………………………330
References……………………………………………………………………………………331
